JETECH HR-101 Hand Riveter

• Package Weight: 7 Kg
• Model: HR101
• Heavy duty rivet gun
• Package Dimensions: 37.5 x 37.5x x26.5 cm
• Easy to operate

Direction

• Drill a hole in the works
• Plug-in the rivet.
• Relax the grip handle, plug-in the head.
• Clamp the grip handle, break the mandrel of rivet
• Relax the handle, downward the mandrel of rivet of course drop.

Selection of rivet size

Before riveting, there must be a hole in the material to be riveted

Matching of hole and rivet sizes are very important. For example, were the

Outer diameter of the rivet is 3.2mm, the hole diameter should be between

3.3mm and 3.4mm. The rivet should be 4mm longer than the thickness of

Object to be riveted.

Maintenance

• If dust and dirt gather in the jaw case, there by hampering smooth movement of the parts, loosen the head screw with the spanner and remove spring, jaw pusher and jaws. After cleaning them, replace them as before, making sure that the jaw pusher point is properly set in the concave head of the jaws.
• Occasional application of ordinary machine oil to the jaw case will ensure smooth movement of parts.
